Nanovers

Quantum Shieldz Nanovers

Close-up of a Quantum Shieldz Nano Vers V1 electronic component on a circuit board, featuring surrounding electronic parts.

Nanovers™ NE13

Micro chips providing powerful quantum entropy



Nanovers™ NE13 is a device that generates digitized pulses from radioactive decay phenomena. The period of the pulse is entirely random. With simple programming, you can create perfect randomness using these pulses.

Small integrated circuit chips on a white background

  • • Providing quantum entropy seeds using radioactive isotopes.

    • True Random Output (Active High)

    • Up to 15 Pulses/sec (Typical)

  • • Operating Temperature : -20ºC to + 85ºC

    • Voltage : 3.3 volts

    • Current : 800 uA

    • Pakage type : 12QFN

    • Size (L x W x H) : 3.0 x 3.0 x 0.8 (mm)

  • • Simple Random Number Generator

    • Encryption / Decryption System

Nanovers™ NC11

EYL’s quantum random number generation and encryption technologies as a System on Chip (SOC)



Nanovers™ NC11 is the word’s first SoC product that combines QRNG technology and encryption technology, implementing encryption and authentication functions in hardware. When integrated into small IoT devices, it can create a highly fast and secure cryptographic communication environment.

Two microchips, one with visible text and the other showing a grid of pins.

  • • Equipped with ARM 32-bit Cortex-M4 CPU

    • Encryption hardware accelerator (AES 128/192/256, SHA-2)

    • Hardware security module: Flash embedded for secure key storage

    • Cryptographic key generation based on QRNG

  • • Pakage type : 144BGA

    • Size (L x W x H) : 10.0 x 10.0 x 1.2 (mm)

  • • All IoT devices requiring security

Nanovers™ NC12

A security chip further reinforced with a security module and resistance against side-channel attacks in hardware



Nanovers™ NC12 is an upgraded version of NC11, with enhanced encryption capabilities and added physical security features such as self-destruct functionality.

close-up of two microchips, one showing circuit contacts and the other labeled 'QCC 2.0 2219'

  • • Equipped with an ARM32-bit Cortex-M4 CPU with an FPU

    • Encryption hardware accelerator (AES 128/192/256, SHA-2, RSA 1024/2048/3096/4096, ECC, LEA 128/192/256, ECDH, ECDSA, HMAC)

    • Hardware security module and resistance against side-channel attacks

    • Self-disassembly feature (self-destruct)

    • Encryption key generation based on QRNG.

  • • Voltage : 3.0 ~ 3.6V

    • Operating Frequency : over 100MHz

    • Pakage type : 144BGA

    • Size (L x W x H) : 10.0 x 10.0 x 1.2 (mm)

  • • All IoT devices requiring security

Nanovers™ NV11

Quantum security technology from EYL and an AI-based encryption chip for video and control signals



Nanovers™ NV11 is a specialized chip for encrypting video and control signals, performing high-quality video compression and encryption functions using AI. It is suitable for systems such as drones, CCTV, and other applications requiring video security.

Two microchips, one showing a patterned grid and the other displaying text and a logo, isolated on a white background.

  • • NC12 features intelligent (AI) video compression technology

    - High-definition video signals from drones, CCTV, etc., are transformed into low resolution using SRCNN technology before encryption and transmission

    - Received data is decrypted and restored to high-definition video

    • Currently under development, scheduled for mass production in 2024

  • • Pakage type : 420FCBGA

    • Size (L x W x H) : 18.0 x 18.0 x 1.4 (mm)

  • • Security video data transmission and reception devices (drone systems, CCTV, wall pads, etc) requiring security
